Erisco Smart Energy Storage System
₦550,000.00
The ERISCO Smart energy storage system includes a 5 kW, 7.5 kW, or 10 kW solar inverter and a lithium battery storage with optional energy ranging from 5120 to 10240 Wh. This one-stop service system makes it more convenient for you to manage your solar home battery storage.
Our flexible modular system can be designed based on your daily household energy consumption. This class-leading power station provides you with the power to run your daily household appliances, cabin workshops, or even provide power backup for your entire house for one or two days, depending on your demands. It is the perfect emergency energy solution for villas, apartments, hotels, and shopping centers.
Description
Description
- Self-consumption and feed-back to the grid.
- Multiple Working Mode: Energy storage mode, load priority mode, power-selling mode and a high-efficiency mode.
- “Time of use” function: a maximum of 6-time segments can be set.
- Inside BMS, support to be charged and discharged according to BMS requirements.
- Support to connect with generator.
- Automatic line-to-battery switch over.
- Mobile APP monitoring.
Additional information
| Model | ERISCO-05 ES, ERISCO-75 ES, ERISCO-10 ES |
|---|
Product specifications
| Specification | ERISCO-05 ES | ERISCO-75 ES | ERISCO-10 ES |
|---|---|---|---|
| Nominal Battery System Voltage | 48VDC | 48VDC | |
| INVERTER OUTPUT | |||
| Rated Power | 5500VA / 5500W | 5500VA / 5500W | 5500VA / 5500W |
| Waveform | Pure Sine Wave | Pure Sine Wave | Pure Sine Wave |
| Nominal Output Voltage RMS | 230V | 230V | 230V |
| Output Voltage Regulation | ±10/-18% | ±10/-18% | ±10/-18% |
| Output Frequency | 50Hz / 60Hz ± 0.5Hz | 50Hz / 60Hz ± 0.5Hz | 50Hz / 60Hz ± 0.5Hz |
| Inverter Efficiency (Peak) | >93% | >93% | >93% |
| Typical Transfer Time | <10ms, 15ms max | <10ms, 15ms max | <10ms, 15ms max |
| AC INPUT | |||
| AC Input Voltage | 230VAC | 230VAC | 230VAC |
| Voltage Range | 170–280VAC(UPS) / 90–280VAC(APL) / 184–253VAC(VDE4105) | 170–280VAC(UPS) / 90–280VAC(APL) / 184–253VAC(VDE4105) | 170–280VAC(UPS) / 90–280VAC(APL) / 184–253VAC(VDE4105) |
| Frequency Range | 50Hz / 60Hz (Auto sensing) | 50Hz / 60Hz (Auto sensing) | 50Hz / 60Hz (Auto sensing) |
| BATTERY | |||
| Note: Below parameters based on one life of lithium battery modular | |||
| Battery | 51.2VDC 100AH 10240Wh | 51.2VDC 100AH 10240Wh | 51.2VDC 100AH 10240Wh |
| Low Battery Cutoff | 44.8DC | 44.8DC | 44.8DC |
| Low Battery Alarm | 46.8VDC | 46.8VDC | 46.8VDC |
| Low Battery Voltage Recover | 48.8VDC | 48.8VDC | 48.8VDC |
| High Voltage Alarm | 58.0VDC | 58.0VDC | 58.0VDC |
| High Battery Voltage Recover | 59.2VDC | 59.2VDC | 59.2VDC |
| SOLAR CHARGER & AC CHARGER | |||
| Maximum PV Array Open Circuit Voltage | 450VDC | 450VDC | 450VDC |
| PV Array MPPT Voltage Range | 150–430VDC | 150–430VDC | 150–430VDC |
| Maximum Solar Charge Current | 100A | 120A | 120A |
| Maximum AC Charge Current | 80A | 100A | 100A |
| Maximum Charge Current | 100A | 120A | 120A |
| Charger Voltage | 28.8VDC | 57.6VDC | 57.6VDC |
| Charging Current | 40A ± 2A | 60A ± 2A | 60A ± 2A |
| Overcharge Protection S.D. | 31VDC | 62VDC | 62VDC |
| OUTPUT | |||
| AC Output | 230VAC (Terminal) | 230VAC (Terminal) | 230VAC (Terminal) |
| BYPASS & PROTECTION | |||
| Nominal Input Frequency | 50Hz or 60Hz | 50Hz or 60Hz | 50Hz or 60Hz |
| Circuit Breaker | FUSE | FUSE | FUSE |
| Bypass Breaker Rating | 32A | 40A | 40A |
| MECHANICAL SPECIFICATIONS | |||
| Machine Dimension (W*H*D) (mm) (Inverter + Battery) | 596×1345×220 | 596×1345×220 | 596×1345×220 |
| Inverter Package Size (mm) | 687×300×680 | 687×300×680 | 687×300×680 |
| Battery (single battery) | 660×285×490 | 660×285×490 | 660×285×490 |
| Net Weight – Inverter (kg) | 20 | 22 | 22 |
| Net Weight – Battery (single battery) (kg) | 48 | 48 | 48 |
| Gross Weight – Inverter (kg) | 22 | 24 | 24 |
| Gross Weight – Battery (single battery) (kg) | 61 | 61 | 61 |
| Standard Warranty | Inverter: 2 years; Lithium battery: 5 years | Inverter: 2 years; Lithium battery: 5 years | Inverter: 2 years; Lithium battery: 5 years |
| OTHER | |||
| Operating Temperature Range | -10°C to 50°C | -10°C to 50°C | -10°C to 50°C |
| Audible Noise | 60dB MAX | 60dB MAX | 60dB MAX |
| Display | LED + LCD | LED + LCD | LED + LCD |
| Standard Warranty | 2 years | 2 years | 2 years |
| CERTIFICATION & STANDARDS | EN/IEC62109-1, EN IEC62109-2 | EN/IEC62109-1, EN IEC62109-2 | EN/IEC62109-1, EN IEC62109-2 |
